Datasheet
Welcome Custom
Item | 15S54Ah-PC01-A | ||
BMS | with Smart BMS | ||
Nominal Voltage | 48V | ||
Nominal Capacity | 54Ah | ||
Charge Current | ≤40A | ||
Discharge Current | ≤45A | ||
| Internal Resistance | ≤50mΩ | ||
Life Cycle | ≥ 2000 cycles | ||
Communication | RS485&RS232 | ||
Weight | 28Kg±3Kg | ||
Dimension | L600mm*W240mm*H120mm |
Our Product
Our Advantage
Customized lithium ion battery
Grade A cells, with real capacity
Sustainable charging current can be reached 1C
With built-in smart BMS to monitor battery status and protect battery in real time
