1.Output is pure sine wave with stable frequecncy and voltage and low distortion.
2.With bidirectional conversion function of step-up and step-down,remote software upgrade management.
3.Millisecond-level response, which can quickly accept sudden load and equipment startup impact.
| Specification Model | 5KW Photovoltaic series | |
| Battery type | LiFePo4 | |
| Rated power | 5KW | |
| Peak power | 6KW | |
| Rating input voltage | 230V AC | |
| Battery input voltage | 40-62V DC | |
| Photovoltaic input | MPPT voltage | 120-500V DC |
| Max solar open circuit voltage | 500V DC | |
| Max solar charging current | 100A | |
| Max AC charging current | 100A | |
| Output characteristic | Output frequency | 50Hz/60Hz±5Hz(self-adaption） |
| Output waveform | Sine wave | |
| THDI | ≤3%THD linear load ≤8%THD non-linear load | |
| Voltage accuracy | ±5% | |
| Communicaiton interface | RS232、RS485、dry contact、CAN | CAN default baud rate：250kbps RS232、RS485 default baud rate：9600bps |
| Protection funciton | Overload, overtemperature protection, overvoltage protection, low-voltage protection and short circuit protection | |
| Operational environment | Working temperature | -20-60℃ |
| Storage humidity | ≤95%RH | |
| Altitude | ≤3000m | |
| Atmospheric pressure | 76-106Kpa | |
